H3C UniServer R5300 G3 24LFF CTO server

Description

H3C UniServer R5300 G3 server
Enterprise-level computing platform to accelerate AI applications

Accelerate deep learning, improve researchers’ work efficiency, high-performance GPU server for heterogeneous computing
H3C UniServer R5300 G3 server is a new generation of GPU server fully independently developed by H3C Group for AI and high-performance computing. It can accelerate the construction of deep learning models, analyze data at extremely fast speeds and export valuable information. Use super computing power to predict future activities, behaviors and trends, and use big data analysis to discover and solve problems hidden in the data.
H3C UniServer R5300 G3 server uses a standard 4U rack server and supports 2 Intel Xeon Scalable Processors: Skylake series or Cascade Lake series. It can be configured with up to 8 double-width GPUs or 20 single-width GPUs, and is built specifically for accelerated computing. Equipped with redundant hot-swappable power supply fans, the leading-edge heat dissipation design ensures that the entire system can run stably 24 hours a day, 7 days a week.

Unprecedented performance
H3C UniServer R5300 G3 supports 8 double-width GPUs or 20 single-width GPUs, providing stronger computing power.
H3C UniServer R5300 G3 adopts PCIe4.0 communication link design for CPU/GPU heterogeneous computing, which can achieve high-speed and low-latency data communication between GPUs, bringing users excellent performance experience.
The host is equipped with high-speed and low-latency network adapters, NVMe drives and the latest APE memory is adapted to bring powerful performance.

Flexible support for deep learning and HPC workloads
H3C UniServer R5300 G3 server supports a variety of mainstream operating systems and virtualization environments, including Microsoft Windows and Linux operating systems, as well as environments such as VMware and H3C CAS, and flexibly adapts to various business needs.
Support existing data center infrastructure standards to accelerate deep learning and HPC applications on the existing basis.

Enterprise-level reliability, availability, and maintainability reduce total cost of ownership
Adopting easy-to-access modular design, it is easier to use and upgrade
N+N redundant power supply and N+1 hot-swappable redundant fans ensure safe and stable operation of the system. Optimized heat dissipation design reduces system power consumption and saves operating costs.
The server integrates a management and monitoring chip and provides powerful centralized management software, which can easily realize remote management and status monitoring of the server and reduce the workload of maintenance personnel.

H3C UniServer R5300 G3 Specifications

GPU Computing Module
Supports 8 double-width GPU modules or 20 single-width GPU modules
Chassis Height
4U
Chipset
IntelC621
Processor
Supports 2 Intel Xeon Scalable Processors: Skylake series or Cascade Lake series CPUs, maximum supported power 205W
GPU Support
Supports up to 8 double-width GPUs or up to 20 single-width GPUs
Memory
Supports 24 DDR4 RDIMMs or LRDIMMs
Supports DDR4 2400/2666/2933MT/s
Storage Controller
Optional high-performance RAID controller, supports RAID0/1/10/5/6/50/60
PCIe Slots
4 single-width PCIe cards, 1 OCP3.0 card and 1 onboard RAID card
Front Hard Drive Expansion
System SAS/SATA/NVMe hard drive configuration:
● 24x 3.5 SAS/SATA/NVMe (16LFF+8NVME or 20LFF+4NVM or 24LFF)
● 12x 3.5 SAS/SATA/NVMe (8LFF+4NVME)
Network
Supports 2×10GE optical ports or 2×25GE optical ports through OCP3.0 expansion
Fan
Supports 8 8056 fans, N+1 hot-swappable redundant fans
Management software
HDM & FIST
Front I/O
2x USB2.0 on the left mounting ear, 1x USB3.0 on the right mounting ear
Rear I/O
2x USB3.0+1x VGA+1x serial+1xHDM management network port is located on the rear panel
Mounting ear
Intelligent mounting ear
Power supply
Up to 4 2000W platinum power supplies, support N+N redundancy
Operating temperature
Operating environment temperature: 5℃~35℃
Storage environment temperature: -40℃~70℃
Operating humidity
Operating environment relative humidity (non-condensing): 8%~90%
Storage environment relative humidity (non-condensing): 5%~95%
Appearance/chassis depth
4U standard chassis;
Without security panel: 174.8mm X 447.0mm X 807mm
With security panel: 174.8mm X 447.0mm X 829mm
Weight
4U standard chassis;
8GPU model fully equipped (8GPU+24LFF) 65.13kg
16GPU model fully equipped (16GPU+24LFF) 57.16kg
Warranty
3 years 5×9, response on the next business day
