HPE Eth 10/25Gb 2P 640SFP28 Adapter-HPE dual-port 25GbE network card

Description

Detail Description 817753-B21 HPE
Manufacturer: HPE
MPN: 817753-B21
Type: Networking
Adapter-Type: Network Adapter 2Ports
SKU: 817753-B21
Spare Part Number: 840140-001
Form Factor: Plug-in card – low profile
Interface (Bus) Type: PCI Express 3.0 x8 / PCI Express 3.0 x4
PCI Specification Revision: PCIe 3.0
Networking
Ports: 25 Gigabit Ethernet x 2
Connectivity Technology: Wired
Data Link Protocol: 10 GIGE, 25 Gigabit LAN
Data Transfer Rate: 25 GBPS
Performance: Bidirectional throughput: 100 Gbps, Bandwidth per port: 50 Gbps
Capacity: Jumbo frame size: up to 9.6 KB
Remote Management Protocol: SNMP
Status Indicators: Link/activity
VLAN support, IPv6 support, full duplex mode, TCP/IP offloading, Quality of Service (QoS), Jumbo Frames support, IPv4 support, PXE support, LACP support, LLDP support, Large Send Offload (LSO), Receive Side Scaling (RSS), UEFI support, TCP Segmentation Offload (TSO), QoS tagging, Extended Message-Signaled Interrupts (MSI-X), UDP/IP offloading, TCP/IP checksum offload, RDMA over Converged Ethernet (RoCE), Virtual Extensible LAN (VXLAN), Network Virtualization using Generic Routing Encapsulation (NVGRE), RDMA over Converged Ethernet (RoCE) v2
Compliant Standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IEEE 802.1Qbg, IEEE 1588v2
Expansion / Connectivity
Interfaces: 2 x 25Gb Ethernet – SFP28
Processor / Memory
Processor: 1 x Mellanox ConnectX-4 Lx – Mellanox Technologies
Power
Power Consumption Operational: 9.7 Watt
Miscellaneous
Compliant Standards: FCC Class A certified, CISPR 22 Class A, ICES-003, EN55024, EN 60950-1, RoHS, ACA, cTUVus, BSMI Class A, VCCI Class A, EN 55022 Class A
Product Dimensions & Weight
Width: 2.7 inch
Height: 1 inch
Depth: 5.8 inch
Weight: 1.00 lbs
Software / System Requirements
OS Required: SuSE Linux Enterprise Server 11, Microsoft Windows Server 2012, Oracle Solaris 11.1, Microsoft Windows Server 2012 R2, VMware ESXi 5.5, Ubuntu 14.04, Red Hat Enterprise Linux 7, Red Hat Enterprise Linux 6.6, Red Hat Enterprise Linux 7.1, Citrix XenServer 6.5, SuSE Linux Enterprise Server 12, Red Hat Enterprise Linux 6.7, Red Hat Enterprise Linux 7.2, VMware ESXi 6.0
Environmental Parameters
Min Operating Temperature: 41 °F
Max Operating Temperature: 140 °F
Humidity Range Operating: 5 – 95% (non-condensing)

Compatibility 817753-B21 HPE Ethernet 10GBPS
HPE Apollo 4000 Series: 4200 Gen9, 4510 Gen10, 4510 Gen9, 4530 Gen9
HPE ProLiant DL Series: DL120 Gen9, DL120 Gen9 Entry, DL160 Gen9, DL160 Gen9 Base, DL160 Gen9 Entry, DL160 Gen9 Performance, DL180 Gen9, DL180 Gen9 Base, DL180 Gen9 Entry, DL180 Gen9 Storage, DL360 Gen10, DL360 Gen10 Base, DL360 Gen10 Entry, DL360 Gen10 High Performance, DL360 Gen10 Low, DL360 Gen10 Performance, DL360 Gen9, DL360 Gen9 Base, DL360 Gen9 CMS, DL360 Gen9 Entry, DL360 Gen9 Performance, DL360 Gen9 Special Server, DL380 Gen9, DL380 Gen9 Base, DL380 Gen9 Entry, DL380 Gen9 High Performance, DL380 Gen9 Performance, DL560 Gen10, DL560 Gen10 Base, DL560 Gen10 Entry, DL560 Gen10 Performance, DL560 Gen9, DL560 Gen9 Base, DL560 Gen9 Entry, DL560 Gen9 Performance, DL580 Gen9, DL580 Gen9 Base, DL580 Gen9 Database, DL580 Gen9 High Performance, DL580 Gen9 SAP HANA Scale-up Base Configuration
HPE ProLiant ML Series:ML350 Gen10, ML350 Gen10 Base, ML350 Gen10 Entry, ML350 Gen10 Performance, ML350 Gen10 Solution, ML350 Gen10 Sub-Entry
HPE ProLiant XL Series:XL230k Gen10 Compute Tray, XL250a Gen9, XL250a Gen9 Accelerator Tray, XL450 Gen10
HPE StoreEasy 1850, 3850 Gateway Single Node
